PWR-C1-715WAC= 715W Cisco 3850 Switch Power Supply Plug In Module

Product Description

Original 715W AC Power Supply PWR-C1-715WAC= for 3850 Series Switch

Cisco's PWR-C1-715WAC= is an enterprise-grade switch engineered to provide robust network capabilities for demanding environments. This versatile switch is designed with features such as advanced security protocols, intelligent traffic management, and support for Power over Ethernet (PoE). The PWR-C1-715WAC offers seamless connectivity, ensuring reliability and efficiency in your network.

Specifications

Power supply rated maximum	715W
Total output BTU (Note: 1000 BTU/hr = 293W)	2465 BTU/hr, 715W
Input-voltage range and frequency	100-240VAC, 50-60 Hz
Input current	10-5A
Output ratings	-56V at 12.8A
Output holdup time	16.7 ms minimum at 100VAC
Power-supply input receptacles	IEC 320-C16 (IEC60320-C16)
Power cord rating	13A
Physical specifications	(H x W x D): 1.58 X 3.25 X 12.20 in
Operating temperature	23 to 113°F (-5 to 45°C)
Storage temperature	-40 to 158°F (-40 to 70°C)
Relative humidity operating and nonoperating noncondensing	5 to 90% noncondensing
Altitude	10,000 ft. (3000 meters), up to 45°C
MTBF	Calculated MTBF must be greater than 300,000 using Telcordia SR-332, Method 1, Case 3. Demonstrated MTBF is 500,000 hr (with 90% confidence level).
EMI and EMC compliance	FCC Part 15 (CFR 47) Class A ICES-003 Class A EN 55022 Class A CISPR 22 Class A AS/NZS 3548 Class A BSMI Class A (AC input models only) VCCI Class A EN 55024, EN300386, EN 50082-1, EN 61000-3-2, EN 61000-3-3 EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN 61000-6-1
Safety compliance	UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
LED indicators	“AC OK”: Input power to the power supply is OK “PS OK”: Output power from the power supply is OK

Compare to Similar Items

Product Code	PWR-C1-350WAC	PWR-C1-440WDC	PWR-C1-715WAC	PWR-C1-1100WAC
Power supply rated maximum	350W	440W	715W	1100W
Total output BTU (Note: 1000 BTU/hr = 293W)	1207BTU/hr, 350W	1517BTU/hr, 440W	2465 BTU/hr, 715W	3793 BTU/hr, 1100W
Input-voltage range and frequency	100-240VAC, 50-60 Hz	-36VDC to -72VDC	100-240VAC, 50-60 Hz	115-240VAC, 50-60 Hz
Input current	4-2A		10-5A	12-6A
Output ratings	-56V at 6.25A	-56V at 7.86A	-56V at 12.8A	-56V at 19.64A
Output holdup time	16.7 ms minimum at 100VAC	> 2ms at -48VDC	16.7 ms minimum at 100VAC	10 ms minimum at 102.5VAC
Power-supply input receptacles	IEC 320-C16 (IEC60320-C16)	Terminal strip	IEC 320-C16 (IEC60320-C16)	IEC 320-C16 (IEC60320-C16)
Power cord rating	10A	20A at 100VDC	13A	13A
